| DF |
|
| |
■ Forging rocker arm with 45 carbon steel, greatly improve flex resistance
■ Not easy to rollover body ,Max. turned 130 degrees only.
■ Long time overload is not easy to deformation
■ All shaft after heat treatment
■ Pump body overload protection down smoothly use safety
■ Lifting down by handle or foot easy to use
■ With imported seal chrome plated piston to improve the service life
■ Frame design strong capacity is strong |
| |
Item | DF 2.5T | DF 3.0T | Capacity Q | (kg) | 2500 | 3000 | Min.fork height H | (mm) | 75 | 75 | Max.fork height H1 | (mm) | 188 | 188 | Steering wheel | (mm) | 180X50 | 180X50 | Load roller | (mm) | 74X70 | 74X70 | Size of fork ExS | (mm) | 160 | 160 | Width overall forks B | (mm) | 550/685 | 550 / 685 | Fork length L | (mm) | 1150/1220 | 1150 /1220 | Net weight | (kg) | 65 | 69 |
|
|
|
|
